| User Capacity |
10,000 user |
| Transaction |
160,000 Transaction |
| Finger Sensor |
CMOS (Infared Optical) |
| Identification Time |
<= 1 Sec. |
| Matching |
1 : 1 and 1: N |
| False Acception Rate(FAR) |
<= 0.0001% |
| False Rejection Rate(TRR) |
<= 1% |
| Communication Type |
RS232, RS485, TCP/IP, USB2.0 V. |
| Baud rate(bps) |
9,600 , 38,400 , 115,200 |
| LCD Display |
Light 128x64 dot |
| Power Requirement |
12-24Vdc relay output 3A |
| Operating Temperature |
0 C - 45 C |
| Operating Humidity |
20% - 80% |
| Access control output |
26 bit Wiegand Access Control |
| Software Support |
WindowsXP, Vista, Windows7 |
| Size |
195(L)*140(W)*40(H) MM |
|
